| Model | TD-50E(L) | ||
| Reference Number | 591241 | 591242 | |
| Voltage | 110V-1P | 220V-1P | |
| Motor Frequency | 60 Hz | 50 Hz | 60 Hz |
| Motor Rated Current | 14 A | 7.0 A | 8.4 A |
| Motor Power | 1.1KW(1.47hp) | ||
| Motor Rated Speed | 3360 rpm | 2800 rpm | 3360 rpm |
| Cable Length | 6.5 m | ||
| Flexible Drive Shaft Length | 2.53 m | ||
| Surface pretreatment grade and reference standards | ST3（SSPC-SP11) | ||
| Packing Size | 60x34x40 cm | ||
| Net/Gross weight | 35 / 40 kg | ||
| * The above data is based on laboratory tests, and there may be some deviations depending on the experimental conditions and the use environment. | |||
